Grandstream GWN7664E | AX6000 Wi-Fi 6 Access Point | Power Adapter Not Included

Deliver enterprise-grade wireless performance with the Grandstream GWN7664E, a high-performance AX6000 Wi-Fi 6 access point designed for medium-to-large businesses, multi-floor buildings, and high-density commercial or residential deployments. With dual-band 4×4:4 MU-MIMO, OFDMA technology, and up to 6Gbps aggregate wireless throughput, it delivers fast, stable connectivity that scales with your network, and it is easily managed through Grandstream’s cloud or on-premise platforms. Note that the power adapter is not included; the GWN7664E is designed to be powered via PoE/PoE+.

• Wi-Fi Standard: 802.11ax (Wi-Fi 6), AX6000 class
• Antenna Configuration: Dual-band 4×4:4 MU-MIMO with DL/UL OFDMA
• Wireless Throughput: Up to 6Gbps aggregate
• Wired Throughput: Up to 5Gbps aggregate
• Network Ports: 2x 2.5 Gigabit Ethernet ports
• Power: PoE/PoE+ (auto-detect); power adapter not included
• Coverage Range: Up to 175 metres
• Concurrent Clients: Up to 512 Wi-Fi devices
• Management: Embedded controller, GWN.Cloud, or GWN Manager
• Ideal For: SMBs, multi-floor buildings, high-density commercial and residential deployments
• High-density performance: OFDMA and MU-MIMO handle many simultaneous devices without slowdowns.
• Fast wired backhaul: Dual 2.5 Gigabit ports keep pace with high wireless throughput.
• Flexible power options: Self power adaptation automatically detects PoE or PoE+.
• Extended coverage: Sophisticated internal antenna design supports up to 175 metres of range.
• Simple network management: Manage locally through the embedded controller or remotely via GWN.Cloud.
• Voice-ready: Optimised for voice-over-Wi-Fi and seamless pairing with Grandstream Wi-Fi IP phones.

As more devices connect to a single network, standard Wi-Fi access points can struggle to maintain performance in busy environments such as offices, apartment buildings, or commercial spaces. The GWN7664E addresses this with 802.11ax OFDMA technology, which divides channels more efficiently so multiple devices can be served simultaneously, reducing latency even when hundreds of clients are connected.

Its dual 2.5 Gigabit ports and support for up to 6Gbps aggregate wireless throughput help ensure the wired connection doesn’t become a bottleneck for the faster wireless speeds Wi-Fi 6 makes possible, making it a practical fit for networks that are scaling up bandwidth-heavy applications alongside everyday browsing and voice traffic.

Key Features

AX6000 Wi-Fi 6 Performance

Delivers up to 6Gbps aggregate wireless throughput using dual-band 4×4:4 MU-MIMO with DL/UL OFDMA technology, ideal for dense, high-demand environments.

Dual 2.5 Gigabit Ports

Two 2.5GbE network ports provide up to 5Gbps aggregate wired throughput, keeping the wired connection in step with faster wireless speeds.

Self Power Adaptation

Automatically detects PoE or PoE+ power input, simplifying installation across different network setups. Power adapter not included.

Extended Coverage & Beamforming

A sophisticated internal antenna design and beamforming technology focus signal strength toward connected clients, supporting coverage of up to 175 metres.

High Client Capacity

Supports up to 512 concurrent Wi-Fi clients, making it suitable for high-density deployments such as offices, campuses, and multi-tenant buildings.

Advanced Management

Manage locally through the embedded controller (up to 50 APs) or remotely at scale with GWN.Cloud or GWN Manager for on-premise administration.

Enterprise Security

Features anti-hacking secure boot, digital signature-based data and control lockdown, and a unique security certificate with a random default password per device.

Multiple SSIDs & QoS

Configure up to 32 SSIDs with individual client settings, captive portals, and bandwidth limits, alongside advanced QoS for low-latency, real-time applications.

Use Cases

• Small-to-Medium Business: Provide fast, reliable Wi-Fi across offices and shared workspaces.
• Multi-Floor Buildings: Extend consistent coverage across multiple floors with strong signal penetration.
• High-Density Deployments: Support hundreds of concurrent devices in commercial or residential settings.
• Voice-over-Wi-Fi: Deliver reliable, low-latency connectivity for Grandstream Wi-Fi IP phones and other VoIP devices.
• Managed Multi-Site Networks: Administer several access points remotely through GWN.Cloud or GWN Manager.

Is It Right?

This access point is a great choice if you:

• Need enterprise-grade Wi-Fi 6 performance for a busy or growing network.
• Support a high number of concurrent wireless clients.
• Want flexible PoE/PoE+ powering without being tied to a specific adapter.
• Run voice-over-Wi-Fi or other latency-sensitive applications.
• Manage multiple access points locally or across several sites.

You may want to consider another option if you:

• Need a power adapter included, since this model requires PoE/PoE+ or a separately purchased adapter.
• Are deploying in a small home with only a handful of devices.
• Require an outdoor-rated access point, as this model is designed for indoor use.

Specifications

FAQs
