GRANDSTREAM GWN7670WM WALL-MOUNTED DUAL-BAND WI-FI 7 ACCESS POINT 3.6GBPS 2.5G POE+

Overview

Bring next-generation Wi-Fi to offices and small-to-medium businesses with the Grandstream GWN7670WM Wall-Mounted Wi-Fi 7 Access Point, an enterprise-grade 802.11be access point built for medium-to-high density environments. Delivering up to 3.6Gbps of aggregate wireless throughput and a 2.5 Gigabit port with PoE+, the GWN7670WM combines next-generation wireless performance with a stylish, sprayable shell designed to blend into any interior.

Whether mounted in-wall or on-wall, the GWN7670WM pairs dual-band 2×2:2 MIMO with DL/UL OFDMA, MLO, and 4096-QAM modulation with advanced QoS and mesh networking, supporting up to 256 concurrent clients. It’s built for small-to-medium businesses that want the speed and efficiency of Wi-Fi 7 without the visible bulk of a traditional access point.

Quick Specs

• Product Type: Wall-Mounted Dual-Band Wi-Fi 7 (802.11be) Access Point
• Aggregate Wireless Throughput: Up to 3.6Gbps
• Aggregate Wired Throughput: Up to 2.5Gbps
• Antenna Configuration: Dual-band 2×2:2 MIMO with DL/UL OFDMA
• Wi-Fi 7 Technologies: MLO, 4096-QAM, Multi-RU, Preamble Puncturing
• Concurrent Clients: Up to 256
• Network Port: 1 x 2.5 Gigabit port with PoE+
• Design: Stylish, sprayable shell for in-wall or on-wall mounting
• Connectivity: Bluetooth Low Energy (BLE) 5.3 with BT location
• Management: Controller-less embedded web UI; GDMS Networking and GWN Manager support
• Security: WPA3, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot
• Ideal For: Small-to-medium businesses, offices, and medium-to-high density wireless deployments

Why Buy

• Next-generation Wi-Fi speed: 3.6Gbps aggregate wireless throughput, MLO, and 4096-QAM modulation deliver faster, more efficient connections than previous Wi-Fi generations.
• Blends into any space: A stylish, sprayable shell lets the GWN7670WM match different décor styles while mounting cleanly in-wall or on-wall.
• High-capacity wired backhaul: A 2.5 Gigabit port with PoE+ keeps the wired connection from becoming a bottleneck for Wi-Fi 7 speeds, while simplifying installation with a single cable.
• Efficient bandwidth use: Multi-RU and Preamble Puncturing technology improve bandwidth utilisation and resistance to interference in busy RF environments.
• Scales with demand: Support for up to 256 concurrent clients suits medium-to-high density office and business deployments.
• Flexible management: A controller-less design with an embedded web interface, plus GDMS Networking and GWN Manager support, fits deployments from a single AP to large multi-site networks.
• Built-in security: WPA3 support, anti-hacking secure boot, and a unique security certificate per device help keep the network protected.

Insights

The Grandstream GWN7670WM is Grandstream’s first Wi-Fi 7 access point built specifically for in-wall and on-wall mounting, bringing 802.11be performance to spaces where a conventional ceiling-mounted AP isn’t the right fit — offices, meeting rooms, retail counters, and small business premises where appearance matters as much as performance.

Its sprayable shell means the unit can be finished to match the surrounding wall or décor, letting it sit discreetly in a room rather than standing out as visible networking hardware. Underneath that design sits full Wi-Fi 7 capability: MLO (Multi-Link Operation) combines multiple frequency bands into a more resilient connection, while 4096-QAM modulation pushes more data through each transmission for a meaningful step up over Wi-Fi 6.

With a 2.5 Gigabit port with PoE+, the GWN7670WM avoids the common bottleneck of pairing next-generation wireless speeds with an ordinary Gigabit uplink, and its controller-less design keeps setup simple whether it’s deployed as a standalone AP or as part of a larger, GDMS-managed network.

Key Features

Wi-Fi 7 (802.11be) Technology

Built on the latest Wi-Fi 7 standard, the GWN7670WM delivers faster speeds, lower latency, and improved efficiency for medium-to-high density environments.

3.6Gbps Aggregate Wireless Throughput

With dual-band 2×2:2 MIMO and DL/UL OFDMA technology, the GWN7670WM delivers strong aggregate wireless performance and a sophisticated antenna design for expanded coverage.

Stylish, Sprayable Shell

A sprayable shell allows the GWN7670WM to be finished to match different décor styles, helping it integrate cleanly into offices, retail spaces, and other business environments.

2.5 Gigabit Port with PoE+

A single 2.5 Gigabit network port with PoE+ provides high-capacity wired backhaul alongside simplified power delivery, avoiding the need for a separate power outlet.

MLO, 4096-QAM, and Advanced Wi-Fi 7 Technologies

MLO (Multi-Link Operation) optimises spectrum resource utilisation for a smoother experience across connected devices, while 4096-QAM modulation, Multi-RU, and Preamble Puncturing improve data rates and bandwidth efficiency.

256 Concurrent Clients

The GWN7670WM supports up to 256 concurrent Wi-Fi client devices per access point, suiting medium-to-high density office and business environments.

Bluetooth Low Energy 5.3 with BT Location

Integrated BLE 5.3 support with BT location adds capability for proximity and location-based applications alongside standard Wi-Fi connectivity.

Controller-Less Management

The GWN7670WM uses a controller-less, distributed network management design, with the controller embedded directly in the product’s web interface, and is also supported by GDMS Networking and GWN Manager for centralised administration.

Advanced QoS and Mesh Networking

Support for advanced QoS, mesh networking, and captive portals helps maintain performance for real-time applications such as voice over Wi-Fi.

Robust Security

Support for WPA3, WPA/WPA2-PSK, and WPA/WPA2 Enterprise encryption, along with anti-hacking secure boot and a unique security certificate per device, helps protect both the network and the access point.

Use Cases

• Small-to-Medium Businesses: Deliver Wi-Fi 7 speeds to offices and workspaces with a clean, discreet installation.
• Meeting Rooms: Support high-bandwidth video conferencing and collaboration tools with next-generation Wi-Fi.
• Retail Stores: Provide reliable in-store Wi-Fi for staff devices, POS systems, and guest access.
• Hospitality: Deliver strong, unobtrusive Wi-Fi coverage in guest rooms and common areas.
• Medium-to-High Density Offices: Support up to 256 concurrent clients across busy workspaces.
• Voice-over-Wi-Fi Deployments: Pair with Grandstream’s Wi-Fi capable IP phones for reliable wireless voice communication.

Is It Right?

This access point is a great choice if you:

• Want next-generation Wi-Fi 7 speeds for your office or business.
• Prefer a discreet, wall-mounted access point over a visible ceiling unit.
• Want a device that can be finished to match your interior décor.
• Need high-capacity 2.5 Gigabit wired backhaul with simplified PoE+ power.
• Need to support up to 256 concurrent clients per access point.
• Plan to manage multiple access points through GDMS Networking or GWN Manager.

You may want to consider another option if you:

• Need outdoor or weatherproof-rated Wi-Fi coverage (consider the GWN7670LR instead).
• Don’t yet have Wi-Fi 7 capable client devices and don’t need the extra headroom.
• Require long-range coverage across large outdoor or campus areas.
• Have a smaller budget and don’t require the latest Wi-Fi 7 standard.

Specifications

Compatibility

• Grandstream Wi-Fi Capable IP Phones: Designed for seamless voice-over-Wi-Fi connectivity with Grandstream’s Wi-Fi enabled IP phones.
• GDMS Networking: Grandstream’s cloud-based management platform for centralised AP monitoring and configuration.
• GWN Manager: On-premise Wi-Fi management platform for larger, self-hosted deployments.
• PoE+ Switches and Injectors: Compatible with standard PoE+ power sources for the 2.5 Gigabit port.
• Standard Wall Boxes: Fits standard in-wall electrical box dimensions for flush installation, or can be mounted directly on-wall.

Setup

1. Choose an installation method — mount the GWN7670WM in-wall using a standard wall box, or on-wall using the supplied mounting hardware.
2. Connect the 2.5 Gigabit port to your network using a compatible PoE+ switch or injector.
3. Access the embedded web interface to configure basic network and Wi-Fi settings.
4. Configure SSIDs, security settings, and VLANs as required for your deployment.
5. Add the access point to GDMS Networking or GWN Manager if centralised management across multiple units is required.
6. Test wireless and wired connectivity to confirm coverage and performance in the installed location.
