Grandstream GWN7660ELR Outdoor Wi-Fi 6 Access Point – AX3000, 300m Range, IP68 & 2.5G SFP

Overview

Extend enterprise-grade Wi-Fi 6 coverage into the harshest outdoor environments with the Grandstream GWN7660ELR Outdoor Wi-Fi 6 Access Point, a long-range AX3000 access point built for high-density networks that demand both performance and durability. Combining 3Gbps aggregate wireless throughput, a 300-metre coverage range, IP68 weatherproof and dust-proof protection, and a 2.5 Gigabit SFP port, the GWN7660ELR is engineered for enterprises, multi-floor offices, warehouses, hospitals, schools, and other large-scale outdoor deployments.

Built with dual-band 2×2:2 MU-MIMO and XTRA Range technology, the GWN7660ELR supports up to 256 concurrent clients while withstanding operating temperatures from -30°C to 60°C. A Gigabit Ethernet port and a 2.5 Gigabit SFP port, both with PoE/PoE+, give network planners the flexibility to run high-capacity fibre or copper backhaul to each access point.

Quick Specs

• Product Type: Outdoor Long-Range Wi-Fi 6 (802.11ax) Access Point
• Wireless Class: AX3000
• Aggregate Wireless Throughput: Up to 3Gbps
• Antenna Configuration: Dual-band 2×2:2 MU-MIMO with XTRA Range technology
• Coverage Range: Up to 300 metres
• Concurrent Clients: Up to 256
• Ethernet Ports: 1 x Gigabit RJ45 (PoE/PoE+), 1 x 2.5 Gigabit SFP (PoE/PoE+)
• Weatherproofing: IP68 weatherproof and dust-proof casing
• Operating Temperature: -30°C to 60°C
• Connectivity: Bluetooth Low Energy (BLE) 5.2
• Management: Embedded controller, GWN.Cloud, and GWN Manager support
• SSIDs: Up to 32 total (16 per radio)
• Ideal For: Enterprises, multi-floor offices, warehouses, hospitals, schools, and outdoor campuses

Why Buy

• Built for the outdoors: IP68 weatherproof and dust-proof casing, together with a -30°C to 60°C operating range, allows the GWN7660ELR to run reliably in extreme conditions.
• Long-range coverage: Up to 300 metres of coverage helps reduce the number of access points needed across large outdoor areas or campuses.
• High-capacity backhaul: A 2.5 Gigabit SFP port alongside a Gigabit RJ45 port, both PoE/PoE+ capable, supports fibre or copper uplinks for demanding network designs.
• Strong Wi-Fi 6 performance: 3Gbps aggregate wireless throughput and dual-band MU-MIMO with OFDMA help maintain performance in high-density client environments.
• Scales to hundreds of devices: Support for up to 256 concurrent clients and 32 SSIDs suits large public, campus, or enterprise deployments.
• Flexible management: An embedded controller, GWN.Cloud for unlimited free cloud management, and GWN Manager for on-premise control of up to 3,000 APs give administrators options at any scale.
• Built-in security: Anti-hacking secure boot, digital signature lockdown, and a unique security certificate per device help protect the network from tampering.

Insights

The Grandstream GWN7660ELR is designed for organisations that need to extend Wi-Fi 6 performance well beyond a typical indoor deployment — think campus courtyards, warehouse yards, hospital grounds, school playing fields, and other large open-air spaces where signal has to travel far and hardware has to survive the elements.

Its IP68-rated casing and wide operating temperature range set it apart from standard indoor access points, allowing it to be mounted outdoors without an enclosure. Combined with XTRA Range antenna technology, it’s built to hold a stable connection across distances where ordinary APs would drop off.

On the wired side, the 2.5 Gigabit SFP port is a notable step up from the single Gigabit port found on many outdoor APs, giving network designers the headroom to fully utilise the access point’s Wi-Fi 6 throughput without the uplink becoming a bottleneck. Whether managed locally through the embedded controller or centrally via GWN.Cloud or GWN Manager, the GWN7660ELR is built to fit into deployments ranging from a single outdoor zone to large multi-site rollouts.

Key Features

IP68 Weatherproof and Dust-Proof Design

The GWN7660ELR is built with IP68-rated weatherproof and dust-proof casing, along with heat-resistant construction, allowing it to operate reliably in demanding outdoor conditions.

3Gbps Aggregate Wireless Throughput

With dual-band 2×2:2 MU-MIMO and OFDMA technology, the GWN7660ELR delivers strong Wi-Fi 6 performance suited to high-density client environments.

300-Metre Extended Range

XTRA Range antenna technology and a sophisticated antenna design extend coverage up to 300 metres, reducing the number of access points needed for large outdoor areas.

Gigabit and 2.5 Gigabit SFP Ports

The access point includes a Gigabit Ethernet (RJ45) port and a 2.5 Gigabit SFP port, both supporting PoE/PoE+, giving network designers flexible options for fibre or copper backhaul.

Wide Operating Temperature Range

Rated to operate between -30°C and 60°C, the GWN7660ELR is designed to keep working through extreme heat and cold.

256 Concurrent Clients and 32 SSIDs

The GWN7660ELR supports up to 256 concurrent Wi-Fi client devices and 32 SSIDs (16 per radio), making it suitable for high-density public or enterprise deployments.

Bluetooth Low Energy 5.2

Integrated BLE 5.2 support adds capability for location-based services and proximity applications alongside standard Wi-Fi connectivity.

Flexible Management Options

An embedded controller manages up to 50 local GWN access points, while GWN.Cloud offers free, unlimited cloud-based AP management and GWN Manager provides on-premise control for up to 3,000 access points.

Advanced QoS and Mesh Networking

Support for advanced QoS, mesh networking, and captive portals helps maintain performance for real-time applications such as voice over Wi-Fi, while extending network flexibility across larger sites.

Robust Security

Anti-hacking secure boot, digital signature-based data and control lockdown, and a unique security certificate with a random default password per device help protect the access point and network from unauthorised access.

Use Cases

• Enterprise Campuses: Extend Wi-Fi 6 coverage across outdoor courtyards, walkways, and parking areas.
• Warehouses and Yards: Provide reliable outdoor connectivity for scanning, logistics, and IoT devices.
• Hospitals: Cover outdoor grounds and between-building areas with dependable, weatherproof Wi-Fi.
• Schools: Extend network access to sports fields, quads, and outdoor learning spaces.
• Multi-Floor Offices: Bridge coverage gaps between buildings or across large outdoor office parks.
• Voice-over-Wi-Fi Deployments: Pair with Grandstream’s Wi-Fi capable voice and video IP phones for reliable outdoor communication.

Is It Right?

This access point is a great choice if you:

• Need Wi-Fi 6 coverage across large outdoor areas or campuses.
• Require IP68-rated weatherproof and dust-proof protection.
• Want extended coverage of up to 300 metres per access point.
• Need a 2.5 Gigabit SFP port for high-capacity backhaul.
• Are deploying in extreme temperature conditions, from -30°C to 60°C.
• Need to support up to 256 concurrent clients on a single AP.
• Plan to manage multiple access points via GWN.Cloud or GWN Manager.

You may want to consider another option if you:

• Only need indoor Wi-Fi coverage without weatherproof requirements.
• Have a smaller deployment that doesn’t need 2.5 Gigabit backhaul.
• Need an in-wall access point instead of an outdoor-mounted unit.
• Have a limited budget and don’t require enterprise-grade outdoor durability.

Specifications

Compatibility

• Grandstream Wi-Fi Capable IP Phones: Designed for seamless voice-over-Wi-Fi connectivity with Grandstream’s Wi-Fi enabled voice and video IP phones.
• GWN.Cloud: Grandstream’s free, unlimited cloud-based Wi-Fi management platform.
• GWN Manager: On-premise Wi-Fi management platform supporting up to 3,000 access points.
• PoE/PoE+ Switches and Injectors: Compatible with 802.3af/802.3at PoE power sources on both the RJ45 and SFP ports.
• SFP Transceiver Modules: Compatible with standard 2.5 Gigabit SFP transceivers for fibre or copper backhaul.

Setup

1. Mount the GWN7660ELR outdoors using the supplied mounting hardware, positioning it vertically for optimal weatherproof performance.
2. Connect the RJ45 or SFP port to your network using a compatible PoE/PoE+ switch or injector.
3. Access the embedded web interface to configure basic network and Wi-Fi settings.
4. Configure SSIDs, security settings, and VLANs as required for your deployment.
5. Add the access point to GWN.Cloud or GWN Manager for centralised management across multiple sites.
6. Test wireless coverage and throughput across the intended outdoor coverage area.
7. Monitor performance through your chosen management platform and adjust channel or power settings as needed.
